- Hardened and ground Z-axis guideway
- Guaranteed concentricity of the spindle nose ≤ 0.015 mm
- Spindle holder Camlock DIN ISO 702-2 No. 5
- Motor protection switch
- Main motor electrically braked
- Clockwise/anticlockwise rotation switchable on the bed slide
- Two-channel safety electronics
- Switch with life cycle calculation tested in accordance with EN ISO 13849
- Perfectly concentric main spindle guarantees high load capacity due to mounted precision tapered roller bearings
- With safety device to prevent simultaneous operation of tapping and feed mechanism
- Safety handwheels with disengagement function in the X and Z axes
- All gear wheels of the feed gear made of steel, hardened and ground, shafts on needle bearings All components are lubricated in an oil bath
- Simple feed operation
- One change gear position
- Switch cabinet with Optimum control system
- Coolant pump with coolant tank and level indicator. Container can be removed for easy cleaning
- LED machine lamp in the machine housing
- Machine base in sturdy steel construction
- Emergency stop switch on the right and left
- Lockable main switch
- Three-jaw lathe chuck included in the scope of delivery
- SWH included in scope of delivery
You will receive the 3-year Stürmer warranty for this item when you register online.
Bemærk
Det viste produkt kan afvige alt efter konfiguration af udstyr og tekniske detaljer. Vær opmærksom på leveringsomfang og produktbeskrivelse.
Tilbehør medfølger kun, hvis det er anført i leveringsomfanget
